Industrial Laser Marking Solutions for Wood

1 / 1

Industrial Laser Marking Solutions for Wood

Customization:	Available
Laser Visibility:	Visible
Applicable Material:	Nonmetal

Send Inquiry

Product Description

Basic Specifications

Model NO.

KT-LC40

Cooling System

Water Cooling

Technical Class

Pulse Laser

Laser Wavelength

CO2 Laser

Type

CO2 Laser Marking Machine

Marking Method

Scanning Marking

Drive Type

Hybrid Servo Drive

Certification

CE, RoHS, ISO 9001

Marking Area

100X100mm

Laser Power

40 Watt

HS Code

8456100090

Production Capacity

300 units Per Month

Product Overview

The KT-LC is a low-power CO2 Laser Marking machine designed for precision marking on non-metal material surfaces such as plastic, cardboard, and leather. Equipped with a machine-integrated high-power motor and a high-speed lifting platform, it offers a cost-effective marking solution.

⚙️

Digital System

Equipped with a high-speed digital scan system and high-quality optical lens for excellent focalization.

💻

Smart Control

Fully adjustable laser power via software. Compatible with CorelDraw, AutoCAD, and Photoshop.

❄️

Advanced Cooling

Integrated pump allows high-speed flow to assist with efficient air and water cooling.

Technical Parameters

Marking Depth	0.001~2mm (depends on material)
Laser Wavelength	10.64um
Laser Power	40W
Lifespan	2000 hours (replaceable laser tube)
Mark Line Width	0.2mm
Marking Field	100x100mm / 175x175mm / 200x200mm
Marking Speed	0-7000mm/s
Minimum Character	0.9mm
Repeating Precision	±0.01mm
Cooling Style	Water Cooling
Power Consumption	≤0.6kw
Power Supply	220V/50Hz

Applicable Materials

Suitable for the majority of nonmetal materials including:

Leather and Cloth
Wood and Bamboo
Paper and Organic Materials
Plastic and Epoxy Resin

Logistics & Warranty

Packaging

Plywood Case

Gross Weight

120kg

Dimensions

1305x560x1090mm

Delivery

Within 7 days

Service Commitments:

One year free warranty (Glass tube: 3 months).
Free fixture design as per customer requirements.
Full technical support and software assistance included.

Frequently Asked Questions

What materials can this CO2 marking machine handle?

It is designed for non-metal materials, including leather, cloth, wood, bamboo, paper, plastic, and epoxy resin.

Is the marking software easy to use?

Yes, the software supports automated coding, serial numbers, and barcodes. It is compatible with CorelDraw, AutoCAD, and Photoshop files (PLT, AI, DXF, BMP, etc.).

What is the lifespan of the laser tube?

The CO2 glass laser tube has a service life of approximately 2000 hours. Once it exceeds this time, you can simply replace the tube to continue operation.

How fast can this machine mark?

The machine features a high-speed galvanometer system reaching marking speeds of 0-7000mm/s with a repeating precision of ±0.01mm.

What are the cooling requirements?

This model uses a water cooling system combined with a high-speed air cooling pump to ensure stable performance during operation.

What is the warranty policy?

We provide a one-year warranty for the machine and a three-month warranty for the glass laser tube. Technical support is provided for free.
