Advanced Laser High-Speed Drilling System for Precision Engineering

Customization: Available
After-sales Service: One Year Warranty
Warranty: One Year Warranty

Product Description

Overview & Basic Info
Model NO.
AT-61166
Origin
China
Package Size
150.00cm * 90.00cm * 150.00cm
Package Gross Weight
2000.000kg
Product Description
The Laser High-Speed Drilling System is a galvanometer-based precision laser processing equipment that combines high-power fiber laser technology with high-speed precision galvanometer control. It enables ultra-fine, high-speed micro-hole processing on thin sheet materials, with a minimum hole diameter of 0.02mm and positioning accuracy up to 2μm. It is widely suitable for precision drilling needs in industries such as electronics, automotive, aerospace, and medical devices, offering a cost-effective solution for micron-level micro-hole processing.
Product Features
Utilizes a single-mode fiber laser with excellent reflection isolation and diffraction-limited beam quality.
High-precision servo cutting head with auto-focus capability and fast response.
Precision optical path and beam control structure for superior spot control.
Linear gantry dual-drive platform with acceleration exceeding 1G.
High-precision 5-axis control system with path optimization and nesting capabilities.
Ultra-high-speed drilling mode exceeding 50 holes per second.
High-precision off-axis visual positioning system for secondary part positioning.
High-flatness marble platform with fully enclosed structure for long-term stability.
Minimum hole diameter down to 0.05mm with smooth cuts and no slag.
Business Scope
Operations include technical services, technology development, consulting, and exchange. Specialized in computer software and hardware wholesale/retail, import and export of technology, and graphic design. Sales coverage includes functional glass, optical materials, optical instruments, semiconductor device equipment, experimental analysis instruments, CNC machine tools, electronic components, electromechanical equipment, welding equipment, fiber optics, and photovoltaic components.
Product Parameters
Category Parameter FM -LPCD1500/3000
LaserWavelength1060~1080nm
LaserPeak Power1500W (3000W)
LaserModulation Frequency1~50kHz
LaserBeam Quality M²<1.05
XY StageTravel600*600mm / 800*800mm
XY StageRepeatability≤±0.005mm
XY StagePositioning Accuracy≤±0.02 mm
XY StageAcceleration≤1G
Z AxisTravel150mm
Visual PositioningAccuracy±0.01mm
CapabilityMin Hole Diameter0.05mm
CapabilityProcessing Thickness≤2mm (5mm)
CapabilityDrilling Speed>50 holes/s
CapabilityMaterialsMetals, alloys, ceramics
EnvironmentCooling MethodAir cooling
DimensionsMachine Size1500*1600*1900mm
WeightTotal Weight1500Kg
Detailed Photos
Frequently Asked Questions
What is the minimum hole diameter this system can achieve?
The system can achieve an ultra-fine minimum hole diameter of 0.02mm, with a kerf width down to 0.05mm depending on the material.
Which materials are suitable for processing with this laser system?
It is designed for precision processing of various metals, alloys, and ceramic materials.
How fast is the drilling capability?
The system features an ultra-high-speed drilling mode that can exceed 50 holes per second for hole diameters between 0.02mm and 0.2mm.
What is the positioning accuracy of the XY stage?
The XY stage provides a positioning accuracy of ≤±0.02 mm and a repeatability of ≤±0.005mm.
Does the system require a complex cooling setup?
No, the system utilizes an efficient air-cooling method, making it easier to maintain and integrate into various environments.
Can it process curved surfaces or tubes?
Yes, by adding an optional rotary axis, the system enables circular tube cutting and specialized drilling tasks.
